Physical properties were determined on specimens prepared under laboratory conditions using applicable ASTM procedures. Actual field conditions may vary and yield different results; therefore, data is subject to reasonable deviation. Data should not be used for specification purposes.
PenePrime 500 is a water-borne epoxy primer to be used in conjunction with the Sauereisen line of coatings, linings and flooring materials. PenePrime is specifically formulated to penetrate deep within concrete substrates. It is recommended to ensure maximum adhesion where conventional primers may not easily penetrate, or where solvent thinned primers are undesirable.
This primer is an integral part of the aforementioned linings in that it seals porous substrates and promotes adhesion of the specified protective material. 500 helps reduce offgassing from concrete. It offers easy application properties to reduce total down time.
CHARACTERISTICS
Specifically formulated to deeply penetrate concrete substrates.
Promotes tenacious adhesion of Sauereisen protective systems.
Easy to apply – brush or roll.
Waterborne – no noxious or toxic odors during application.
Physical properties were determined on specimens prepared under laboratory conditions using applicable ASTM procedures. Actual field conditions may vary and yield different results; therefore, data is subject to reasonable deviation.
ConoWeld 501 is a primer to be used in conjunction with the Sauereisen line of epoxy coatings, linings and flooring materials. ConoWeld 501 is applied by spray, brush or roller over concrete and steel.
This primer is an integral part of the Sauereisen lining system in that it seals porous substrates and promotes adhesion of the specified protective material. Easy application properties help to reduce total downtime.
CHARACTERISTICS
Seals porous substrates and promotes adhesion of topcoats.
Physical properties were determined on specimens prepared under laboratory conditions using applicable ASTM procedures. Actual field conditions may vary and yield different results; therefore, data is subject to reasonable deviation.
Sauereisen ConoPrime 502 is a two-part epoxy primer to be used in conjunction with the Sauereisen ConoFlex 381. Recommended for use on concrete and various substrate types. Formulated to provide a chemical bond with ConoFlex Urethane 381.
ConoPrime 502 is specifically formulated to easily penetrate concrete substrates. It is recommended to ensure maximum adhesion where conventional primers may not penetrate.
This primer is an integral part of the lining in that it helps seal porous substrates and promotes adhesion of the protective material. 502 helps reduce offgassing from concrete. It offers easy application properties to reduce total down time.
CHARACTERISTICS
Promotes tenacious adhesion of Sauereisen 381 and 309
Physical properties were determined on specimens prepared under laboratory conditions using applicable ASTM procedures. Actual field conditions may vary and yield different results; therefore, data is subject to reasonable deviation. Data should not be used for specification purposes.
Sauereisen VEPrime 550 is a vinyl ester primer to be used in conjunction with Sauereisen vinyl ester systems. The function of 550 is to promote a tenacious bond of Sauereisen vinyl ester topcoats to concrete and steel substrates.
VEPrime is a packaged, pre-measured unit for use with the following Sauereisen materials: Vinyl Ester Polymer Concrete 410, NovolaK Fast-Trak VE Lining 441, NovolaK VEGlaze 472, NovolaK Vinyl Ester FibreLine 440 and NovolaK Vinyl Ester Polymer Concrete 465. These products comprise a system for chemical-resistant construction of sumps, dikes, containment areas, trenches, walls and other structural support columns or bases.
Physical properties were determined on specimens prepared under laboratory conditions using applicable ASTM procedures. Actual field conditions may vary and yield different results; therefore, data is subject to reasonable deviation.
Sauereisen Hi-Temp Primer No. 560 is a single-component, moist-cured urethane primer to be used in conjunction with several Sauereisen coating and lining systems. The function of No. 560 is to promote a tenacious bond of Sauereisen epoxy, vinyl ester and urethane topcoats to concrete and steel substrates.
High Temperature Conductive Primer No. 562 is available. Consult Sauereisen for details.
Hi-Temp Primer is primarily specified for applications subject to elevated temperatures common to flue gas, pulp & paper and process tank environments. Under challenging conditions, No. 560 is designed to resist heat to the same degree as the chemical-resistant topcoat used with it. No. 560 is especially useful where substrate or atmospheric moisture may interfere with the cure of epoxy or vinyl ester primers. The Primer is supplied as a single component to expedite its placement.
Spray applied with conventional airless spray equipment
Engineer:
Project Details:
Restoration of 6’ diameter x 17’ deep steel pump station wet well.
Surface preparation included abrasive blasting the steel substrate to remove any surface rust and to provide a profile for the material to mechanically bond to.
After priming with the 501 ConoWeld, the entire wet-well was lined with Sauereisen’s 210S fiber reinforced SewerGard at 60-mils.
To ensure a pin-hole free application, a 20-mils topcoat of the 210G SewerGard epoxy glaze was spray applied over the entire surface.
02. PROJECT PROFILE
Pretreatment 1st & 2nd Stage Cyanide Tanks Lining System
Location:
Owner:
Engineer:
General Contractor:
Sauereisen Representative:
Products:Array
Method of Application:
Trowel, Brush, Roll
Engineer:
Project Details:
Concrete surfaces had suffered various degrees of corrosion.
All damaged concrete was removed down to sound concrete and all areas in need of repair were rebuilt using F-121, followed by application of. 501 ConoWeld Primer at 8-10 mils on all surfaces.
262 NovolaK Epoxy, an aggregate filled system, was applied by trowel to all surfaces at 125 mils. Followed by an 8-10 mil sealer coat of 228 Epoxy NovolaK Glaze.
A high voltage spark test was preformed on the completed lining and all necessary repairs were made prior to final curing and returned to service.
